| Photo(s) donated by Michael Feldt. Visit Michael's web site at http://www.indianaradios.com/. To see all the photos Michael has contributed to RadioGallery.net, click here. |
| There were two versions of this superheterodyne radio made, the 9 which had a 8 tube chassis and a three tube power supply/amplifier and the 9B which had 9 tubes on the chassis and no power supply/amplifier. This was Scott's first radio to use the new screen grid tubes (UX-222) that had just come out earlier that year. I acquired this set in 1990 from a Washington State audio enthusiast in a trade for a Counterpoint D90 amplifier. Tube Line Up: 01A...R.F. Amplifier 01A...1st. Detector / Mixer 40...Oscillator 22...1st. I.F. Amplifier 22...2nd. I.F. Amplifier 22...3rd. I.F. Amplifier 01A...2nd. Detector 12A...Audio Driver 50...Audio Output (Located on separate power supply / amplifier) 81 x 2...Rect. (Located on separate power supply / amplifier) |
|
|
|
|
